HDA36100U44X - Schneider Electric PowerPact H 100A 600V 3 Pole I-Line Circuit Breaker Micrologic 6.2A 14kA

HDA36100U44X

HDA36100U44X is a Schneider Electric PowerPact H series molded case circuit breaker designed for 3-pole, 600 Volt applications with a 100 ampere rating.This circuit breaker features an I-Line style plug-in mounting, a 14kA interrupting rating at 600V, and includes a Micrologic 6.2A electronic trip unit providing LSIG protection with current limiting capabilities.

• Amperage: 100A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 14kA at 600V, 18kA at 480V, 25kA at 240V
• Series/Frame: PowerPact H
• Trip Unit: Micrologic 6.2A Electronic LSIG
• Connection: ABC Phase
• Certifications: UL Listed, CSA, CE, CCC, IEC
• 80% Rated
• Current Limiting Type

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36100U44X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long Time, Short Time, Instantaneous and Ground Fault Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Solid State

Product Data

• UPC : 785901133452
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
