HDA36060U33XYE - Square D PowerPacT H 60 Amp 3-Pole 600VAC Circuit Breaker

HDA36060U33XYE

HDA36060U33XYE is a Square D PowerPacT H molded case circuit breaker designed for industrial power distribution applications. This 60 amp, 3-pole unit operates at 600VAC and features I-line plug-in construction with Micrologic 3.2S trip unit for reliable overcurrent protection. The breaker delivers 14kA interrupting capacity at 600VAC and supports standard 80% continuous current rating with ABC phase connection capability.

• Amperage: 60 Amp
• Voltage: 600VAC
• Poles: 3-Pole
• Frame Type: PowerPacT H (HDA)
• Mounting: I-Line Plug-In
• Trip Unit: Micrologic 3.2S
• Interrupting Capacity: 14kA at 600VAC
• Continuous Rating: 80%
• Phase Connection: ABC
• Certifications: UL 489, CSA, IEC, CE marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36060U33XYE
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : H Frame
• Protection : Solid State

Product Data

• Weight : 5
