HDA260506 - Square D PowerPact H 50A 600V 2 Pole I-Line Plug-In Circuit Breaker

HDA260506

HDA260506 is a Square D PowerPact H molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 2-pole breaker features a 50A current rating, 600V AC voltage rating, and is built for I-Line style plug-in mounting. It offers thermal-magnetic trip protection and is suitable for applications requiring high interrupting capacity and secure connections. The HDA260506 is part of the PowerPact H series, known for durability and performance in demanding environments. It supports both overcurrent and short-circuit protection, making it ideal for use in panelboards and switchgear. The breaker is UL listed and designed for reverse fed applications, ensuring compliance with safety standards.

• Part Number: HDA260506
• Manufacturer: Square D
• Series: PowerPact H
• Poles: 2
• Rated Current: 50A
• Voltage Rating: 600V AC
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 18kA @ 480V
• Protection Type: Thermal-Magnetic
• Frame Type: H-Frame
• Control Type: Toggle
• Certification: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA260506
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
