HDA260305 - Square D 30A 2 Pole 600VAC Thermal Magnetic Circuit Breaker I-Line PowerPact H Frame

HDA260305

HDA260305 is a Square D 2 pole thermal magnetic molded case circuit breaker rated for 30 amps and 600VAC/250VDC operation.This PowerPact H frame breaker features an I-Line style plug-in connection, long time and instantaneous trip functions, and a high interrupting rating suitable for industrial applications. It supports line and load lug connections with wire gauge compatibility from AWG 14 to AWG 3/0 aluminum or copper. Certified to UL, CSA, CE, NEMA, NOM, IEC, and RoHS standards, it ensures reliable protection against overloads and short circuits.

Key Specifications
• Amperage: 30 Amps
• Voltage: 600VAC, 250VDC
• Poles: 2
• Interrupting Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Frame Type: PowerPact H (HDA)
• Connection Type: I-Line Style Plug-In
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Terminal Connection: Line and Load Lug
• Wire Gauge: AWG 14 to AWG 3/0 Aluminum/Copper
• Certifications: UL, CSA, CE, NEMA, NOM, IEC, RoHS
• Actuator Type: Toggle
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HDA260305
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : CA



Product Data

• UPC : 785901416555
• GTIN : 00785901416555
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
