FH36100CBA - Square D Molded Case Circuit Breaker 100A 600V 3-Pole I-Line

FH36100CBA

FH36100CBA is a Square D molded case circuit breaker designed for I-Line panelboards and switchboards with thermal magnetic protection. This 3-pole breaker delivers reliable performance in industrial and commercial power distribution applications requiring high interrupting capacity and dependable trip characteristics. The I-Line style plug-in connection ensures quick installation and removal for maintenance or replacement in standard panelboard configurations. Key Specifications

• Amperage: 100A
• Voltage: 600VAC
• Poles: 3
• Frame Type: FH (F-Frame)
• Mounting Mode: I-Line Style Plug-In
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous functions
• Interrupting Rating: 25kA at 480V, 18kA at 600V, 65kA at 240V
• Magnetic Hold Current: 900A
• Temperature Rating: 40 degrees C
• Certifications: UL, CSA, CE, HACR
• Dimensions: 6.4 inches H x 4.5 inches W x 4.13 inches D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FH36100CBA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901774761
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6.272
