EHD3080 - Westinghouse 80A 480V 3-Pole Molded Case Circuit Breaker F Frame

EHD3080

EHD3080 is a Westinghouse 3-pole molded case circuit breaker rated for 80 amperes and 480 volts AC, designed for industrial power distribution applications.This thermal magnetic breaker features an F frame design with a fixed thermal and magnetic trip unit, suitable for panel mounting. It provides an interrupting rating of 14,000 amperes at 480 VAC and 10,000 amperes at 250 VDC, ensuring reliable protection. The breaker complies with UL standards and includes standard pressure load and line terminals. Dimensions are approximately 6 inches high, 4.13 inches wide, and 3.38 inches deep.

• Manufacturer: Westinghouse (Eaton / Cutler-Hammer)
• Amperage: 80 A
• Voltage: 480 VAC, 250 VDC
• Poles: 3
• Frame Type: F Frame, EHD model
• Trip Unit: Fixed thermal magnetic
• Interrupt Rating: 14 kA at 480 VAC, 10 kA at 250 VDC
• Mounting Type: Panel mount (bolt-on)
• Terminal Type: Standard pressure load and line terminals
• Dimensions: 6" H x 4.13" W x 3.38" D
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3080
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317594
• GTIN : 00786679317594
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.3
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
