EHD3060 - Cutler Hammer 60A 480V 3-Pole Molded Case Circuit Breaker, Series C, Thermal Magnetic Trip

EHD3060

EHD3060 is a Cutler Hammer Series C molded case circuit breaker designed for 60 ampere, 480 volt applications with 3 poles.This EHD3060 breaker features a thermal magnetic trip unit with non-interchangeable trip, 14 kA interrupt rating at 480 VAC, and bolt-on mounting. It is a complete F-frame breaker with feed-thru connection, suitable for three-phase power distribution. The breaker includes long-time and instantaneous trip functions and line and load side lug terminals.

Key Specifications
• Manufacturer: Cutler Hammer
• Series: C, Type EHD
• Amperage: 60 A
• Voltage: 480 VAC / 250 VDC
• Poles: 3
• Interrupt Rating: 14 kA at 480 VAC
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Mounting Type: Bolt-On
• Frame Type: F Frame
• Connection: Feed-Thru
• Trip Functions: Long-Time and Instantaneous
• Phase: 3

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3060
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317167
• GTIN : 00786679317167
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
