EHD1070 - Eaton 70A 277/480VAC 1-Pole Molded Case Circuit Breaker, EHD Series, Fixed Thermal/Magnetic Trip, Panel Mount, UL Listed

EHD1070

EHD1070 is a single-pole, molded case circuit breaker from Eaton, designed for reliable circuit protection in commercial and industrial applications.

This Eaton EHD Series breaker features a fixed thermal/magnetic trip unit, panel mounting, and is suitable for use in systems up to 277/480VAC and 125VDC. It offers robust performance with a 70A current rating and is part of the C Series, F-frame family. The breaker is UL Listed for safety and compliance.

Key Specifications
• Amperage: 70A
• Voltage: 277/480VAC, 125VDC
• Poles: 1
• Mounting Type: Panel
• Interrupt Rating: 18 kAIC at 240VAC, 14 kAIC at 480VAC
• Series/Frame: C Series, F-frame, EHD type
• Trip Unit: Fixed thermal, fixed magnetic
• Certifications: UL Listed
• Connection: Feed-thru
• Frequency: 50/60 Hz
• Gross Weight: 1.55 lbs
• Net Weight: 1.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1070
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 70
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078667931738
• GTIN : 00786679317389
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.55
• Certification : UL Listed
