Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EHD1010
EHD1010 is a Cutler Hammer Series C molded case circuit breaker providing reliable branch circuit protection with a 10 Amp rating and 1-pole configuration.This circuit breaker features a fixed thermal-magnetic trip unit, panel mounting, and is rated for 277 Volts AC and 125 Volts DC. It has a 14 kA interrupt rating at 277 VAC and is part of the NEMA F-frame Series C family, suitable for use in panelboards, switchboards, motor control centers, and busway applications.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton Division)
- Part Number: EHD1010
- Amperage: 10 A
- Voltage Rating: 277 VAC, 125 VDC
- Poles: 1
- Interrupt Rating: 14 kA at 277 VAC
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Panel Mount
- Series/Frame: Series C, NEMA F-frame
- Frequency: 50/60 Hz
- Certifications: Meets North American standards
- Part Number: EHD1010
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 277
- Amperage : 10
- Phase : 1
- Poles : 1
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- UPC : 786679317303
- GTIN : 00786679317303
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 2
- Certification : UL Listed
