EHD1015 - Cutler Hammer 15A 277V 1-Pole Series C Molded Case Circuit Breaker F-Frame

EHD1015

EHD1015 is a Cutler Hammer Series C molded case circuit breaker providing reliable 15 amp, 1-pole circuit protection at 277 VAC and 125 VDC.

This Eaton F-frame breaker features a fixed thermal magnetic trip unit with long-time and instantaneous trip functions, 14kA interrupt rating at 480 VAC, and feed-thru connection type. It is designed for single-phase applications with line and load side lug terminals and a durable molded case construction.

• Amperage: 15 A
• Voltage: 277 VAC / 125 VDC
• Poles: 1
• Frame Type: F-Frame
• Trip Unit: Fixed Thermal Magnetic (Long-Time and Instantaneous)
• Interrupt Rating: 14kA at 480 VAC
• Mounting Type: Feed-Thru
• Series: Eaton Series C
• Phase: Single-phase
• Connection: Line and Load Side Lug Terminals
• Certifications: Meets industry standards for molded case breakers

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1015
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : A

Product Data

• UPC : 786679317310
• GTIN : 00786679317310
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.45
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
