Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
EHD1050
EHD1050 is a Westinghouse 50A 1-pole molded case circuit breaker designed for reliable protection in commercial and industrial applications. This breaker features a 277V AC rating, EHD frame, and thermal magnetic trip unit with long-time and instantaneous protection. It is suitable for use in 1-phase systems and offers a 14kA interrupting capacity at 480V. The EHD1050 is a feed-thru, bolt-on breaker with load side lug terminals and non-interchangeable trip for secure operation. This molded case circuit breaker is built to meet industry standards for safety and durability, making it ideal for panel upgrades, replacements, and new installations. The breaker is rated for 40°C ambient temperature and is commonly used in lighting, HVAC, and power distribution systems.
- Part Number: EHD1050
- Manufacturer: Westinghouse
- Amperage: 50A
- Voltage: 277V AC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupt Rating: 14kAIC@480V
- Series/Frame: EHD Frame
- Protection Type: Thermal Magnetic
- Functions: Long-Time and Instantaneous Trip
- Terminals: Load Side Lug
- Standards: UL Listed, CSA Certified
Specifications
- Part Number: EHD1050
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 277
- Amperage : 50
- Phase : 1
- Poles : 1
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Terminal Connection : Load Side Lug
- Frame Size : 100A/F
- Temp Rating : -13–158 °F (-25–70 °C)
- MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : A
Product Data
- UPC : 786679317365
- GTIN : 00786679317365
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 1.65
- Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
- Standards : CSA Certified, IEC Rated, UL Listed
- Certification : CSA Certified, IEC Rated, UL Listed
