EHD1030 - Eaton Series C Molded Case Circuit Breaker, 30A, 277V, 1 Pole, F-Frame, Fixed Thermal/Magnetic Trip, 14kA Interrupt, Feed-Thru, UL Listed

EHD1030

EHD1030 is a single-pole, 30A molded case circuit breaker from Eaton's Series C, designed for reliable circuit protection in commercial and industrial applications.

This Eaton EHD1030 features a fixed thermal/magnetic trip unit, feed-thru connection, and a robust F-frame design. It is suitable for use in 1-phase systems, offering both long-time and instantaneous overcurrent protection. The breaker is UL Listed for safety and compliance.

Key Specifications
• Amperage: 30A
• Voltage: 277V AC, 125V DC
• Poles: 1
• Mounting Type: Feed-Thru
• Interrupt Rating: 14kA @ 277V AC, 18kA @ 125V DC
• Series/Frame: Series C, F-Frame
• Trip Unit: Fixed Thermal, Fixed Magnetic (Non-Interchangeable)
• Certifications: UL Listed
• Connection: Line & Load Side Lug Terminals
• Dimensions: 6" H x 1.38" W x 3.38" D
• Weight: 1.6 lb
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1030
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : A

Product Data

• UPC : 786679317341
• GTIN : 00786679317341
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.6
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
