Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDH2225L
EDH2225L is a Eaton Series C complete molded case circuit breaker designed for reliable electrical protection.This 2-pole circuit breaker features a 225 ampere rating with a voltage rating of 240 Vac and 125 Vdc. It is built on the F-frame Series C platform and includes fixed thermal and magnetic trip units for dependable overcurrent protection. The breaker supports line and load terminals and has a high interrupt rating of 100 kAIC at 240 Vac. It is UL Listed for safety and performance.
- Key Specifications
- Amperage: 225 A
- Voltage Rating: 240 Vac, 125 Vdc
- Poles: 2
- Frame: F-Frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 100 kAIC at 240 Vac
- Terminals: Line and load
- Certifications: UL Listed
- Frequency Rating: 50 to 60 Hz
- Part Number: EDH2225L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDH
- Voltage : 240
- Amperage : 225
- Phase : 2
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
- UPC : 786679454022
- GTIN : 00786679454022
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
