EDH2200 - Westinghouse 200A 240V 2 Pole Bolt-On Circuit Breaker 100kA Interrupt Rating

EDH2200

EDH2200 is a 2 pole, 200 amp, 240 volt bolt-on circuit breaker manufactured by Westinghouse designed for reliable power distribution protection.This Westinghouse EDH2200 circuit breaker features a 200 ampere rating with a 240 VAC voltage rating, 2 poles, and a 100kA interrupting capacity at 240 volts. It uses a bolt-on mounting type and includes a thermal magnetic trip unit for dependable overload and short circuit protection. The breaker is part of the ED series/frame and is UL listed for safety compliance.

Key Specifications
• Amperage: 200 A
• Voltage: 240 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 100kA @ 240V
• Series/Frame: ED
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2200
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 200
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456248
• GTIN : 00786679456248
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
