Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDH2200W
EDH2200W is a Series C F-frame molded case circuit breaker designed for reliable electrical protection in commercial and industrial applications.This Eaton circuit breaker features a fixed thermal and fixed magnetic trip unit, providing consistent overcurrent protection. It is rated for 200A, 240VAC, and 125VDC, with a 100kAIC interrupt rating at 240VAC. The breaker is two-pole and does not include terminals, making it suitable for busbar mounting. It operates at 50/60 Hz and is UL Listed for safety compliance.
- Series C F-frame
- 200A amperage rating
- 240VAC, 125VDC voltage rating
- Two-pole configuration
- Fixed thermal, fixed magnetic trip type
- 100kAIC interrupt rating at 240VAC
- Busbar mounting (no terminals)
- 50/60 Hz frequency rating
- UL Listed
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: EDH2200W
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDH
- Voltage : 240
- Amperage : 200
- Phase : 2
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679456606
- GTIN : 00786679456606
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
