EDH2200Y - Eaton Series C F-Frame 200A 2-Pole Molded Case Circuit Breaker Thermal Magnetic Trip 100kAIC @240V

EDH2200Y

EDH2200Y is a Series C F-frame molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial applications. This 2-pole breaker features a 200A amperage rating and a fixed thermal magnetic trip unit for consistent overcurrent protection. The breaker is rated for 240 Vac and 125 Vdc, with a high interrupt rating of 100kAIC at 240 Vac, making it suitable for demanding electrical environments. It is part of Eaton's Series C family and is UL Listed for safety and compliance. This molded case circuit breaker is designed for standard mounting and features lugs on the line side and a busbar on the load side. The breaker is built for durability and ease of installation, with a compact footprint and robust construction. It is ideal for use in panelboards, switchboards, and other power distribution systems where reliable circuit protection is required.

• Part Number: EDH2200Y
• Manufacturer: Eaton
• Series: Series C
• Frame: F-Frame
• Amperage Rating: 200A
• Voltage Rating: 240 Vac, 125 Vdc
• Number of Poles: 2
• Interrupt Rating: 100kAIC @ 240 Vac
• Mounting Type: Standard
• Line Side Terminal: Lugs
• Load Side Terminal: Busbar
• Tripping Unit: Fixed Thermal Magnetic (T186)
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2200Y
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 200
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 078667945588
• GTIN : 00786679455883
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
