EDH2200L - Eaton Series C F-Frame Molded Case Circuit Breaker 200A 2-Pole 240V

EDH2200L

EDH2200L is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications.

This F-frame molded case circuit breaker features a 200-ampere rating at 240 VAC with 2-pole configuration and line and load terminals. The unit incorporates fixed thermal magnetic trip protection and delivers a 100 kA short circuit interrupt capacity at 240V, making it suitable for demanding electrical systems. The feed-thru connection design allows for flexible installation in power distribution panels and enclosures.

• Amperage: 200A
• Voltage: 240 VAC at 50/60 Hz
• Poles: 2-Pole
• Frame Size: F-Frame
• Series: Series C
• Trip Type: Fixed Thermal Magnetic
• Interrupt Rating: 100 kA at 240V
• Connection Type: Line and Load Terminals
• Configuration: Feed-Thru
• DC Voltage Rating: 125 VDC
• Temperature Rating: 40 Degrees C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2200L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 200
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679454084
• GTIN : 00786679454084
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
