EDB3175 - Westinghouse 175A 240V 3 Pole Molded Case Circuit Breaker Bolt-On F Frame

EDB3175

EDB3175 is a 3 pole, 175 amp, 240 Volt molded case circuit breaker manufactured by Westinghouse, designed for reliable circuit protection.This Bolt-On type breaker features a 22kA interrupt rating at 240V, F frame (Series C) construction, and thermal magnetic trip unit with long time and instantaneous trip functions. It supports load side lug terminals and is suitable for reverse fed applications.

Key Specifications
• Amperage: 175A
• Voltage: 240V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 22kA @ 240V
• Frame/Series: F Frame (Series C)
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Load Side Lug Terminals
• Suitable for Reverse Fed Application
• Manufacturer: Westinghouse

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB3175
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDB
• Voltage : 240
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : F Frame
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78211615276
• GTIN : 00782116152766
• Country of Origin : Mexico
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 3
• Standards : cULus, IEC
• Certification : cULus, IEC
