EDB3100L - Cutler Hammer 100A 3-Pole 240VAC Molded Case Circuit Breaker F-Frame Series C

EDB3100L

EDB3100L is a Cutler Hammer molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This Eaton Series C breaker features a fixed thermal and fixed magnetic trip unit, three poles, and a 100 ampere rating. It supports a maximum voltage of 240 VAC and 125 VDC with a 22 kA interrupt rating at 240 VAC. The breaker is panel mountable and UL listed for safety compliance.

• Manufacturer: Cutler Hammer (Eaton)
• Series: Series C, F-Frame
• Amperage: 100 A
• Poles: 3
• Voltage Rating: 240 VAC, 125 VDC
• Interrupt Rating: 22 kAIC at 240 VAC
• Trip Type: Fixed Thermal / Fixed Magnetic
• Mounting Type: Panel Mount
• Certifications: UL Listed
• Frequency: 50/60 Hz
• Dimensions: 6" H x 4.13" W x 3.38" D
• Weight: Approximately 3 to 4.4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB3100L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDB
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782116976133
• GTIN : 00782116976133
• Country of Origin : Mexico
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 3
• Standards : cULus, IEC
• Certification : cULus, IEC
