Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
EDB24100SA
EDB24100SA is a Schneider Electric Square D 2 pole, 100 amp Bolt-On circuit breaker designed for 480Y/277V AC applications with HACR rating.This E-Frame breaker provides reliable protection against overloads and short circuits in commercial and industrial electrical systems.
- Amperage: 100 Amps
- Voltage Rating: 480Y/277 VAC
- Poles: 2 Pole
- Mounting Type: Bolt-On
- Interrupt Rating: 18 kAIC at 480V
- Series/Frame: E-Frame (EDB Series)
- Trip Unit: Thermal Magnetic
- HACR Rated for HVAC equipment
- Wire Range: AWG 12 to 2/0 Aluminum, AWG 14 to 2/0 Copper
- Certifications: UL Listed
Additional Information
complete with 120V shunt trip
Specifications
- Part Number: EDB24100SA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : EDB Series
- Type : EDB
- Voltage : 480Y/277
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Temp Rating : 104 ¡F (40 ¡C)
- Protection : Thermal Magnetic
Product Data
- GTIN : 03606486143858
- Country of Origin : Mexico
- Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
- Weight : 3.999
- Standards : cULus, IEC
- Certification : cULus, IEC
