ED43B050L - Siemens 50A 480V 3-Pole Molded Case Circuit Breaker, ED Frame, 18kAIC, Thermal Magnetic Trip, UL 489 / IEC 60947-2, Feed-Thru Lug

ED43B050L

ED43B050L - Siemens Sentron molded case circuit breaker, type ED frame, 3-pole, thermal magnetic trip.

Siemens ED43B050L is a standard 40 deg C ED frame circuit breaker with thermal magnetic trip unit, rated for 480 VAC, 50 A, 18 kAIC at 480 V interrupting capacity, line/load lug terminals, and panel mounting. It supports 10 to 1/0 AWG copper/aluminum wire, 50/60 Hz frequency, and meets UL 489 / IEC 60947-2 standards. All ED frame breakers may be reverse connected.

• Part Number: ED43B050L
• Manufacturer: Siemens
• Amperage: 50 A at 40 deg C
• Voltage: 480 VAC
• Poles: 3
• Frame: ED
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 18 kA at 480 VAC
• Mounting Type: Panel
• Wire Size: 10 to 1/0 AWG CU/AL
• Frequency: 50/60 Hz
• Connection: Line/Load Lug

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED43B050L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : ED
• Voltage : 480 AC
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : ED Frame
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643236189
• GTIN : 00783643236189
• Country of Origin : Mexico
• Dimensions : 6.693 x 5.906 x 3.953
• Weight : 3.849
• Certification : Ul Listed, IEC
