Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED43B025L
ED43B025L - Siemens Sentron ED frame molded case circuit breaker with thermal-magnetic trip, rated at 25A, 3 poles, and 18kA interrupt at 480V.This standard 40C breaker features ED frame with standard breaking capacity, non-interchangeable trip unit, and line/load lugs for versatile installation. It meets UL 489 and IEC 60947-2 standards, providing reliable protection against overloads and short circuits in low voltage systems up to 480VAC/250VDC.
- Amperage Rating: 25A
- Poles: 3
- Voltage Rating: 480VAC/250VDC
- Interrupt Rating: 18kA at 480V
- Frame Size: ED
- Trip Unit: Thermal-Magnetic, Non-Interchangeable
- Mounting Type: Feed-Thru with Line/Load Lugs
- Certifications: UL 489, IEC 60947-2
- Temperature Rating: 40C
Specifications
- Part Number: ED43B025L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 480 AC
- Amperage : 25
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643236134
- GTIN : 00783643236134
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 3.943
- Weight : 3.735
- Certification : Ul Listed, IEC
