C25END430T - Cutler Hammer 30A 4 Pole Definite Purpose Contactor 24V AC Coil Metal Mount

C25END430T

C25END430T is a Cutler Hammer 4 pole definite purpose contactor rated at 30A with a 24V AC coil and metal mounting plate. This compact contactor is designed for reliable motor control in HVAC, refrigeration, and industrial applications. The C25END430T features screw/pressure plate and quick connect terminals, non-reversing configuration, and is UL recognized and CSA certified for use in North America and Europe. Its robust construction and RoHS compliance make it suitable for a wide range of demanding environments.

• Part Number: C25END430T
• Manufacturer: Cutler Hammer
• Amperage Rating: 30A (Inductive), 40A (Resistive)
• Coil Voltage: 24V AC, 50/60 Hz
• Number of Poles: 4
• Mounting Type: Metal base plate
• Interrupt Rating: 180A Locked Rotor
• Series/Frame: C25 Series
• Enclosure: Open with metal mounting plate
• Terminals: Screw/pressure plate and quick connect
• Compliance: RoHS, CSA, UL
• Application: HVAC, refrigeration, industrial motor control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 24 VAC coil.

Specifications

• Part Number: C25END430T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 4
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 24
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 24
• Frequency : 50 Hz

Product Data

• UPC : 782113554099
• GTIN : 00782113554099
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 3.75 in x 2.68 in (Length/Depth x Height x Width)
• Weight : 2.3 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA, RoHS, UL Listed
