Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25END430B
C25END430B is a Cutler Hammer definite purpose contactor rated at 30 amps with a 208-240V AC coil and 4 poles.This 4-pole contactor is designed for motor control applications with a 30A inductive and 40A resistive rating, suitable for use in HVAC, refrigeration, and other equipment. It features double quick connect terminals, a metal mounting plate, and is UL recognized and CSA certified. The contactor supports a locked rotor current of 180A and is part of the C25 series, known for reliability and versatility.
- Amperage: 30A inductive, 40A resistive
- Voltage: 208-240V AC coil
- Poles: 4
- Mounting: Metal base plate
- Interrupt Rating: Locked rotor 180A
- Terminals: Double quick connect
- Series/Frame: C25
- Trip Unit: Non-reversing definite purpose
- Certifications: UL recognized, CSA certified, RoHS compliant
Additional Information
This Definite Purpose Contactor includes a 208 VAC coil.
Specifications
- Part Number: C25END430B
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 4
- Configuration : Non-Reversing
- Coil Voltage Maximum : 240
- Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
- Coil Voltage Minimum : 208
- Frequency : 50 Hz
Product Data
- UPC : 782113554082
- GTIN : 00782113554082
- Country of Origin : Dominican Republic
- Dimensions : 5.1 in x 3.7 in x 4.4 in (Length/Depth x Height x Width)
- Weight : 2.05 lb
- Certification : CSA, RoHS, UL Listed
