Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TQD32150X2
TQD32150X2 is a General Electric 3-pole molded case circuit breaker rated for 150 amps and 240 volts AC with a 10 kA interrupt rating and thermal magnetic trip type.This Type TQD circuit breaker features bolt-on mounting, line lug connection, and is designed for three-phase electrical distribution. It complies with UL, CSA, NOM, and IEC standards and is suitable for reverse feed applications. The breaker has a Q-Line frame and provides reliable protection with long-time and instantaneous trip functions.
- Key Specifications
- Amperage: 150 A
- Voltage: 240 V AC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 10 kA @ 240 V
- Trip Type: Thermal Magnetic
- Frame/Series: Q-Line
- Connection Type: Line Lug
- Phase: 3
- Certifications: UL, CSA, NOM, IEC
- Dimensions: 4-1/8 in W x 2-5/8 in D x 6-9/16 in H
Specifications
- Part Number: TQD32150X2
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : TQD
- Voltage : 240
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164131406
- GTIN : 00783164131406
- Weight : 3
