Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TQD32125ST1
TQD32125ST1 is a 3 pole, 125 amp, 240V bolt-on molded case circuit breaker from General Electric's Q-Line series, designed for reliable protection in commercial and industrial applications. This thermal magnetic circuit breaker features a 10kAIC interrupt rating at 240V, load side lug terminals, and a 120V shunt trip for remote operation. It is suitable for use in 3-phase systems and provides both long time and instantaneous trip functions for enhanced safety.
- Part Number: TQD32125ST1
- Manufacturer: General Electric
- Amperage: 125A
- Voltage: 240V AC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 10kAIC @ 240V
- Series/Frame: Q-Line, TQD
- Tripping Unit: Thermal Magnetic
- Shunt Trip: 120V
- Terminal Type: Load Side Lug
- Application: 3 Phase
Specifications
- Part Number: TQD32125ST1
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : TQD
- Voltage : 240
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783164179002
- GTIN : 00783164179002
- Weight : 3
- Certification : UL Listed
