Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TQD32125X2
TQD32125X2 is a General Electric 3 pole, 125 amp, 240 volt bolt-on circuit breaker designed for reliable electrical distribution protection.This thermal magnetic molded case circuit breaker features a Q-Line frame and non-interchangeable trip unit, suitable for main or subfeed applications. It has an interrupt rating of 10kA at 240V and is compatible with A-Series panelboards. The breaker includes line and load side lug terminals and is engineered for industrial and commercial electrical control.
- Amperage: 125 Amps
- Voltage: 240 Volts AC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 10kA @ 240V
- Frame/Series: Q-Line
- Trip Unit: Thermal Magnetic, Non-Interchangeable
- Application: Main or Subfeed Breaker
- Certifications: UL Listed
- Compatible with GE A-Series Panelboards
Specifications
- Part Number: TQD32125X2
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : TQD
- Voltage : 240
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164131437
- GTIN : 00783164131437
- Weight : 3
