Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THJK426200WL
THJK426200WL is a General Electric 2-pole molded case circuit breaker rated for 200 amps and 600 volts designed for industrial applications.THJK426200WL features a thermal magnetic trip unit within the J frame series, providing reliable overcurrent protection. It supports a voltage rating of 600 VAC and 250 VDC, with an interrupting rating of 65 kA at 240 VAC. This breaker is suitable for use in electrical distribution systems requiring robust and durable circuit protection.
- Type: Molded Case Circuit Breaker
- Frame: J Frame
- Amperage: 200 Amps
- Voltage Rating: 600 VAC / 250 VDC
- Poles: 2
- Trip Unit: Thermal Magnetic
- Interrupting Rating: 65 kA at 240 VAC
- Mounting Type: Standard panel mount
- Manufacturer: General Electric
Specifications
- Part Number: THJK426200WL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 200
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 078316404669
- GTIN : 00783164046694
- Weight : 16
