Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TFJ236100
TFJ236100 is a General Electric 3 pole thermal magnetic molded case circuit breaker rated for 100 Amps and 600 Volts with a bolt-on connection.This circuit breaker features a TFJ frame type with a 22kA interrupting rating at 480V, suitable for 3-phase applications. It includes long time and instantaneous trip functions, line and load side lug terminals, and is designed for industrial electrical protection with thermal magnetic trip units.
- Amperage: 100 Amps
- Voltage: 600 Volts AC
- Poles: 3
- Frame Type: TFJ
- Connection Type: Bolt-On
- Interrupt Rating: 22kA @ 480V
- Trip Unit: Thermal Magnetic
- Phase: 3 Phase
- Suitable for Reverse Fed Applications
- Line & Load Side Lug Terminals
- Series: F225 Line
- Certifications: NETA Tested (varies by seller)
Specifications
- Part Number: TFJ236100
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : F225 Line
- Type : TFJ
- Voltage : 600
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 22kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 10
