Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
SGLA26AT6300C
SGLA26AT6300C is a General Electric molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This 600 Amp, 2 Pole breaker operates at a maximum voltage of 600 Volts and features a robust frame suitable for demanding electrical environments. It includes a factory-installed electronic trip unit with front-accessible rating plugs for adjustable amp settings. The breaker is UL489 listed with a maximum short circuit interrupting rating of 200kA at 480 VAC, ensuring high performance and safety compliance.
- Type: SGLA Molded Case Circuit Breaker
- Amperage: 600 Amp
- Number of Poles: 2
- Voltage Rating: 600 Volt
- Frame/Series: SG600 Frame
- Trip Unit: Factory-installed electronic trip unit with rating plugs
- Interrupt Rating: 200kA at 480 VAC
- UL Listed: UL489, File E11592
- Mounting Type: Panel mount compatible with GE type AD panels
Specifications
- Part Number: SGLA26AT6300C
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Spectra Series
- Type : SGLA
- Voltage : 600
- Amperage : 300
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LSI - Long-Time, Short-Time and Instantaneous
- Protection : Solid State
Product Data
- Weight : 20
