RJF36200U33A - Square D 2000A 600V 3 Pole Powerpact R Frame Circuit Breaker

RJF36200U33A

RJF36200U33A is a Square D Powerpact R Frame molded case circuit breaker rated for 2000 amps and 600 volts AC with three poles.This circuit breaker features a 3-pole configuration with a J interrupt rating, suitable for unit mount applications. It is UL 489 listed and CSA approved, designed for industrial power distribution with a breaking capacity up to 65kA at 480V. The breaker dimensions are approximately 16.24 inches high, 16.53 inches wide, and 14.49 inches deep. It includes an electronic trip unit and is part of the Powerpact family, providing reliable protection and performance.

Key Specifications
• Amperage: 2000 A
• Voltage Rating: 600 VAC max
• Poles: 3
• Interrupt Rating: J code (up to 65kA @ 480V)
• Mounting Type: Unit Mount
• Series/Frame: Powerpact R Frame
• Trip Unit: Electronic
• Certifications: UL 489 Listed, CSA Approved
• Dimensions: 16.24" H x 16.53" W x 14.49" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: RJF36200U33A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : RJF
• Voltage : 600
• Amperage : 2000
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Protection : Solid State

Product Data

• UPC : 785901495604
• GTIN : 00785901000000
• Country of Origin : United States
• Dimensions : 16.24 in (412.50 mm) x 16.54 in (420.12 mm) x 14.49 in (368.05 mm) (Height x Width x Depth)
• Weight : 74
• Standards : UL, CSA, NEMA, NMX J-266, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...750 kcmil aluminium/copper
