RGA36100CU31A - Square D 1000A 600V 3-Pole Molded Case Circuit Breaker I-Line Micrologic 3.0

RGA36100CU31A

RGA36100CU31A is a Square D molded case circuit breaker designed for power distribution applications with a 1000 amp rating and 600 volt AC voltage rating.This 3-pole circuit breaker features an electronic trip unit (Micrologic 3.0) and I-Line plug-in mounting style. It provides protection from overloads and short circuits with an 18kA interrupting rating at 600V AC. The breaker is UL 489 listed, CSA NMX, and IEC certified, suitable for use in panelboards and switchboards.

Key Specifications
• Amperage: 1000A
• Voltage: 600V AC, 50/60 Hz
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupting Rating: 18kA at 600V AC
• Trip Unit: Electronic, Micrologic 3.0
• Series/Frame: PowerPact RGA
• Certifications: UL 489, CSA NMX, IEC
• Application: Power distribution, panelboards, switchboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: RGA36100CU31A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : RGA
• Voltage : 600
• Amperage : 1000
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : R Frame
• Protection : Solid State

Product Data

• UPC : 078590149101
• GTIN : 00785901491019
• Country of Origin : Mexico
• Dimensions : 16.24 in (412.50 mm) x 16.54 in (420.12 mm) x 14.49 in (368.05 mm) (Height x Width x Depth)
• Weight : 62.501
• Standards : UL, CSA, NEMA, NMX J-266, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...600 kcmil aluminium/copper
  4 x AWG 3/0...500 kcmil copper
