Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QOU200
QOU200 is a Square D 60 Amp, 2 Pole, 240 Volt QOU Series miniature circuit breaker designed for reliable circuit protection.QOU200 features a non-automatic, common trip design with a toggle actuator and surface mount/DIN rail mounting style. It has a 10kA interrupt rating and is suitable for use in residential and commercial electrical panels requiring a compact, high-quality breaker.
- Key Specifications
- Amperage: 60A
- Voltage Rating: 240V AC
- Number of Poles: 2
- Series/Frame: QOU
- Mounting Type: Surface Mount/DIN Rail
- Interrupt Rating: 10kA
- Trip Unit: Non-Automatic, Common Trip
- Circuit Breaker Actuator: Toggle
- Certifications: UL Listed
Specifications
- Part Number: QOU200
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QO Series
- Type : QOU
- Voltage : 240
- Amperage : 60
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Unit Mount
- Functions : NA - No Overcurrent Protection
- Terminal Connection : Slotted Box Lug
- MCM Size : Min. Wire Size 12 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
- Protection : Non-Automatic
Product Data
- UPC : 785901371717
- GTIN : 00785901371717
- Country of Origin : Mexico
- Dimensions : 4.05 in (102.87 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
- Weight : 0.7
- Standards : UL Listed, CSA
- Certification : UL Listed, CSA
- Wire Size : AWG 12...AWG 2/0 aluminium/copper
