QO220CP - Square D 20 Amp 2-Pole 120/240 VAC Mini Circuit Breaker, QO Series, Plug Mount

QO220CP

QO220CP is a 20 Amp, 2-Pole mini circuit breaker from the Square D QO Series, designed for reliable overload and short-circuit protection in residential and light commercial electrical systems. This breaker features a plug-in mounting design for quick installation and secure connection. The QO220CP is engineered for use in Square D QO load centers and panels, providing dependable protection for branch circuits. Its magnetic thermal trip unit ensures accurate response to overloads and short circuits, while the compact size saves panel space. The breaker is rated for 120/240 VAC and 48 VDC, making it suitable for a wide range of applications.

• 20 Amp current rating
• 2-Pole configuration
• 120/240 VAC, 48 VDC voltage rating
• Plug-in mounting type
• Interrupt rating: 5-10 kA
• QO Series frame
• Magnetic thermal trip unit
• Black color
• Dimensions: 3 in H x 1.5 in W x 2.91 in D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO220CP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QO Series
• Type : QO
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 8 AWG (Cu/Al)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 047569838026
• GTIN : 00047569838026
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.54 lb
• Standards : UL Listed, CSA
• Certification : UL Listed, CSA
• Wire Size : AWG 14 to AWG 8, Copper or Aluminum
