PLA34080CU43A - Square D 800A 3-Pole 480V PowerPacT P Frame Circuit Breaker 100kA Interrupt Rating

PLA34080CU43A

PLA34080CU43A is a Square D PowerPacT P Frame molded case circuit breaker rated for 800 amps, 3 poles, and 480 volts with a 100kA interrupt rating.PLA34080CU43A features an electronic trip unit ET 1.0I, I-Line plug-in mounting, and is designed for protection against overloads and short circuits in electrical systems. It complies with UL 489, CSA, IEC standards, and is CE marked.

• Amperage: 800A
• Voltage: 480V AC
• Poles: 3
• Interrupt Rating: 100kA at 480VAC
• Frame: PowerPacT P
• Mounting Type: I-Line plug-in
• Trip Unit: Electronic trip unit ET 1.0I
• Continuous Current Rating: 80%
• Certifications: UL 489, CSA, IEC, CE marked
• Dimensions: 12.86 x 8.27 x 8.05 inches
• Weight: 32 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PLA34080CU43A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 480
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 606486286008
• GTIN : 03606490000000
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
