NGC308035E - Eaton 800A 3P Series G Circuit Breaker

NGC308035E

NGC308035E Eaton Series G Molded Case Circuit Breaker The Eaton NGC308035E is a high-performance Series G NG-frame molded case circuit breaker designed for industrial power distribution systems that require advanced electronic protection and high interrupting capacity. This breaker features an 800A rating, 3-pole configuration, and a Digitrip 310 RMS electronic trip unit with LSG protection for dependable overload, short-circuit, and ground fault protection. Engineered for switchboards, panelboards, motor control centers, and other demanding commercial and industrial applications, the NGC308035E delivers precise circuit protection while maintaining Eaton's proven Series G reliability and performance. Key Specifications

• Manufacturer: Eaton
• Catalog Number: NGC308035E
• Series: Series G
• Frame Type: NG Frame
• Product Type: Electronic Molded Case Circuit Breaker
• Poles: 3 Pole
• Amperage Rating: 800A
• Voltage Rating: 480VAC Rated, 600VAC Maximum
• Trip Unit: Digitrip 310 RMS
• Trip Functions: LSG (Long-Time, Short-Time, Ground Fault)
• Interrupt Rating: 200kA @ 240VAC
• Interrupt Rating: 100kA @ 480VAC
• Interrupt Rating: 45kA @ 600VAC
• Frequency: 50/60 Hz
• Connection: Line and Load
• Rating: 80% Rated
• Reverse Feed Capable: Yes
• Lugs Included: No
• Mounting: NG Frame
• Standards: UL Listed, CSA Certified, HACR Rated

The NGC308035E combines Eaton's advanced Digitrip 310 RMS technology with comprehensive LSG protection to provide reliable circuit protection and selective coordination in critical power distribution systems. Its robust NG-frame construction and high interrupting capacity make it an excellent choice for industrial and commercial installations. At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.It provides dependable protection and integrates easily in commercial and industrial distribution systems.

• Family: PowerPact NG (NGC)
• Poles: 3
• Amperage: 35 A
• Voltage: 600 Vac
• Mounting: lug-lug mounting
• Trip Unit: Micrologic electronic (per suffix)
• Certifications: UL 489 Listed, CSA Certified

Suffix meanings in this catalog number

• Micrologic electronic trip unit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: NGC308035E
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : NGC
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LSG - Long Time, Short Time and Ground Fault
• Protection : Solid State

Product Data

• UPC : 786685379036
• GTIN : 00786685379036
• Country of Origin : United States
• Dimensions : 6 in x 9 in x 9 in (Length/Depth x Height x Width)
• Weight : 47 lb
• Certification : UL Listed,CSA Certified,HACR Rated
