Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
NGC308033E
NGC308033E is an Eaton Series G electronic molded case circuit breaker from the Cutler-Hammer line. This NG-frame, three-pole breaker uses an electronic LS trip and is rated for 800 A and 480 Vac, with 50/60 Hz operation and interrupting ratings of 200 kAIC at 240 Vac and 100 kAIC at 480 Vac. Key Specifications
- Part Number: NGC308033E
- Manufacturer: Cutler Hammer
- Amperage: 800 A
- Voltage: 480 V
- Poles: 3
- Frequency: 50/60 Hz
- Interrupt Rating: 100 kA
- Frame Size: NG-frame
- Trip Type: Electronic LS
- Trip Type: T167
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: NGC308033E
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : Electronic molded case circuit breaker
- Voltage : 480 V
- Amperage : 800 A
- Phase : 3
- Poles : 3
- AIC rating : 100 kA
- Connection : Bolt-On
- Functions : LS
- Frame Size : NG-frame
- Breaker Type : NG
- Hz : 50/60 Hz
- Protection : Solid State
- Trip Type : Electronic LS
Product Data
- UPC : 786685379012
- GTIN : 00786685379012
- Country of Origin : United States
- Dimensions : 6 in x 9 in x 9 in (Length/Depth x Height x Width)
- Weight : 47
- Certification : CSA Certified,UL Listed,HACR Rated
