ND3800T76W - Eaton Series C Molded Case Circuit Breaker 800A 600V 3-Pole

ND3800T76W

ND3800T76W is an Eaton Series C electronic molded case circuit breaker designed for industrial power distribution and protection applications. This three-pole breaker features an 800-ampere rating at 600 volts AC with electronic LSIG trip unit technology for reliable overcurrent and short-circuit protection. The NG-frame design provides compact integration into electrical panels and switchboards, while the complete breaker configuration comes without terminals for flexible installation options. Compliant with HACR ratings, this breaker delivers consistent performance in demanding environments at 50/60 Hz operation.

• Amperage Rating: 800 A
• Voltage Rating: 600 Vac
• Number of Poles: Three-pole
• Frame Type: NG-frame
• Trip Type: Electronic LSIG (T172)
• Interrupt Rating: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac
• Series: Series C
• Frequency: 50/60 Hz
• Terminals: Without terminals
• Weight: 48 lb
• Compliances: HACR Rated
• UPC: 786679050453

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ND3800T76W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : ND
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Frame Size : N Frame
• Protection : Solid State

Product Data

• UPC : 786679050453
• GTIN : 00786679050453
• Country of Origin : United States
• Dimensions : 21.62 in x 9.63 in x 11.12 in (Length/Depth x Height x Width)
• Weight : 48
• Certification : HACR Rated
