Description
MJM36350
MJM36350 is a Square D 350 Amp, 600 Volt, 3 Pole M Frame molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a unit mount design with a J interrupt rating, providing 65kA interrupting capacity at 480V and 25kA at 600V. It is UL 489 listed and suitable for use in industrial and commercial applications requiring robust circuit protection. The M Frame construction supports up to 350 Amps continuous current and three poles for three-phase power systems.
- Manufacturer: Square D
- Part Number: MJM36350
- Amperage: 350 Amp
- Voltage Rating: 600 Volt AC
- Poles: 3
- Frame Type: M Frame
- Mounting Type: Unit Mount
- Interrupt Rating: 65kA at 480V, 25kA at 600V
- UL Listing: UL 489
Specifications
- Part Number: MJM36350
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : MJM
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : M Frame
- Protection : Solid State
Product Data
- Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
- Weight : 29
