LXD62B600 - Siemens 600A 600V 2-Pole Molded Case Circuit Breaker Bolt-On Type LXD Sentron Series

LXD62B600

LXD62B600 is a Siemens Sentron Series molded case circuit breaker designed for 600 amps and 600 volts with 2 poles and bolt-on mounting.This Siemens LXD type breaker features thermal magnetic protection with long-time and instantaneous trip functions. It has a 35kA interrupt rating at 480V and 25kA at 600V, suitable for single-phase applications. The breaker is UL listed for reverse fed applications and includes a non-interchangeable trip unit. Lugs are not included.

• Manufacturer: Siemens
• Series: Sentron
• Type: LXD Molded Case Circuit Breaker
• Amperage: 600A
• Voltage: 600V
• Poles: 2
• Mounting: Bolt-On
• Interrupt Rating: 35kA @ 480V, 25kA @ 600V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous functions
• Phase: Single Phase
• UL Listed for reverse fed applications
• Weight: 15.25 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: LXD62B600
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : LXD
• Voltage : 600
• Amperage : 600
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : LD Frame
• Temp Rating : -13¡F-158¡F
• Protection : Thermal Magnetic

Product Data

• UPC : 783643213739
• GTIN : 00783643213739
• Country of Origin : Mexico
• Dimensions : 8.661 x 12.992 x 6.696
• Weight : 15.201
• Certification : Ul Listed
