LGL36400U44X - Square D PowerPacT L 400A 3 Pole Molded Case Circuit Breaker 600VAC 35kAIC Solid State LSIG

LGL36400U44X

LGL36400U44X is a 3 pole, 400A, 600VAC molded case circuit breaker from the Square D PowerPacT L series, featuring solid state LSIG trip protection and a 35kAIC interrupting rating at 480VAC. This breaker is designed for reliable protection in commercial and industrial power distribution systems. It features a unit mount design, feed-thru connection type, and MicroLogic 6.3A trip unit with long time, short time, instantaneous, and ground fault protection. The LGL36400U44X is UL 489 listed and meets CSA, NEMA, IEC, and RoHS standards.

• Part Number: LGL36400U44X
• Manufacturer: Square D
• Series: PowerPacT L
• Amperage: 400A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Unit
• Interrupt Rating: 35kAIC at 480VAC
• Frame Type: LGL
• Protection: Solid State LSIG
• Connection Type: Feed-Thru
• Certifications: UL, CSA, NEMA, IEC, RoHS

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product e(more...)

Specifications

• Part Number: LGL36400U44X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : LGL
• Voltage : 600
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : Lug
• Frame Size : L Frame
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Protection : Solid State

Product Data

• UPC : 785901984818
• Country of Origin : Mexico
• Dimensions : 13.4 in (340 mm) x 5.5 in (140 mm) x 4.3 in (110 mm) (Height x Width x Depth)
• Weight : 17.181
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 2 x AWG 2/0...500 kcmil aluminium/copper
