Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
KDC3350L
KDC3350L is an Eaton Series C molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This 350 amp, 3-pole circuit breaker features a K-frame design with fixed thermal and fixed magnetic trip units. It is rated for 600 Vac and 250 Vdc operation with a frequency rating of 50 to 60 Hz. The breaker has an interrupt rating of 35 kAIC at 480 Vac and 65 kAIC at 240 Vac, providing robust fault current interruption capability. It includes aluminum terminals for line and load connections and is UL Listed for safety and performance.
- Key Specifications
- Amperage Rating: 350 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Three-pole
- Frame Size: K-frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 35 kAIC at 480 Vac, 65 kAIC at 240 Vac
- Frequency Rating: 50 to 60 Hz
- Terminal Material: Aluminum
- Terminals: Line and load
- Certifications: UL Listed
- Part Number: KDC3350L
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : KDC
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
- Weight : 12
