JXD63B225H - Siemens 225A 600V 3 Pole JD Frame Molded Case Circuit Breaker Thermal Magnetic

JXD63B225H

JXD63B225H is a Siemens 225 amp, 600 volt, 3 pole molded case circuit breaker designed for reliable circuit protection.This Siemens JXD63B225H circuit breaker features a JD frame with thermal magnetic trip unit, suitable for low voltage applications. It supports a 100% rated current capacity with a 25 kA interrupt rating at 600 VAC and 35 kA at 480 VAC. The breaker is bolt-on mounted and rated for operation at 40 degrees Celsius. It accommodates wire sizes from 3/0 AWG to 500 kcmil copper and 4/0 AWG to 500 kcmil aluminum conductors.

Key Specifications
• Amperage: 225 A
• Voltage Rating: 600 V AC
• Number of Poles: 3
• Frame/Series: JD
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 25 kA @ 600 V, 35 kA @ 480 V
• Mounting Type: Bolt-On
• Operating Temperature: 40¡C
• Wire Size Range: 3/0 AWG to 500 kcmil Cu, 4/0 AWG to 500 kcmil Al
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: JXD63B225H
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : JXD
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13¡F-158¡F (-25¡C - 70¡C)
• Protection : Thermal Magnetic



Product Data

• UPC : 783643229327
• GTIN : 00783643229327
• Country of Origin : Mexico
• Dimensions : 8.661 x 12.992 x 6.697
• Weight : 15.201
• Standards : RoHS
• Certification : UL, IEC
