Reference images. Contact us for photos of the available unit.
Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Eaton
- Brand
- Bussmann
- Sub-Category
- Fuse Block
- Series
- JM Modular
- Rated current
- 30
- Voltage
- 600V
- Interrupting rating
- 200kA
- Connection
- Box lug
- Fuse class
- J
- Country of origin
- Mexico
- Temp Rating
- -13°F to 158°F (-25°C to 70°C)
- Mounting
- Box Lug With Clip Reinforced Spring
- UPC
- 051712514651
- GTIN
- 00051712514651
Show all specifications (3 more)
- Dimensions
- 3.30 in x 3.40 in x 2.30 in
- Weight
- 0.1
- Certification
- CE, CSA Certified 47235-6225-01, RoHS Compliant, UL Listed E14853 IZLT and IZLT7
Product description & additional details
JM60030-3CR
JM60030-3CR is a three-pole modular fuse block designed for Class J fuses, rated for 0-30A and 600V AC, featuring box lug connections and a robust 200kAIC interrupt rating. This Eaton Bussmann Series JM fuse block provides reliable circuit protection for industrial and commercial power distribution applications, supporting easy DIN-rail or panel mounting, toolless modular assembly, and optional open fuse indication for fast troubleshooting. The block is spring reinforced for secure connections and includes phase barriers for added safety.
- Part Number: JM60030-3CR
- Manufacturer: Eaton Bussmann
- Series: JM Modular
- Amperage Rating: 0-30A
- Voltage Rating: 600V AC
- Number of Poles: 3
- Fuse Class: Class J
- Interrupt Rating: 200kAIC
- Connection Type: Box Lug
- Mounting Type: DIN-Rail or Panel
- Certifications: UL Listed, CSA Certified, RoHS Compliant
- Special Features: Spring Reinforced, Toolless Modular Design, Optional Open Fuse Indication
Specifications
- Part Number: JM60030-3CR
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Fuse Block
- Family : JM Modular
- Voltage : 600
- Amperage : 30
- AIC rating : 200kA
- Connection : Box lug
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- Fuse Class : J
- Mounting : Box Lug With Clip Reinforced Spring
Product Data
- UPC : 051712514651
- GTIN : 00051712514651
- Country of Origin : Mexico
- Dimensions : 3.30 in x 3.40 in x 2.30 in
- Weight : 0.1
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- Certification : CE, CSA Certified 47235-6225-01, RoHS Compliant, UL Listed E14853 IZLT and IZLT7
Return eligibility: what to know before ordering
Return requests must be made within 30 days of shipping and require authorization. Used, installed, energized, or tested items are not eligible. A restocking fee of up to 35% may apply. Review the full policy before purchase.
Product-specific restrictions apply. International orders are non-cancellable and non-refundable under the policy.
Warranty supplied by Essential Electric
Warranty coverage is provided by Essential Electric, subject to the product and policy terms. Essential Electric is an independent supplier. Surplus or discontinued inventory may not qualify for the original manufacturer’s warranty.
