JJL26200 - Square D PowerPact J Molded Case Circuit Breaker 200A 2 Pole 600VAC 250VDC

JJL26200

JJL26200 is a Square D PowerPact J molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This breaker features a thermal-magnetic trip unit and is rated for 200 amps, 2 poles, and up to 600VAC or 250VDC. The JJL26200 is a unit mount, current limiting, adjustable type circuit breaker with lugs on both line and load sides. It is UL 489 listed and suitable for applications requiring high interrupt capacity and dependable performance in demanding environments.

• 200 Amp Amperage Rating
• 600 VAC / 250 VDC Maximum Voltage
• 2 Poles
• Unit Mount
• 25kA Interrupt Rating at 600VAC
• PowerPact J Frame
• Thermal-Magnetic Trip Unit
• Current Limiting
• Adjustable
• UL 489 Listed
• Lug Terminal Connection
• 3/0 AWG Wire Size

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJL26200
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJL
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : J
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : CA

Product Data

• UPC : 785901955900
• GTIN : 00785901955900
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.3
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
