JDL36225SA - Square D 225 Amp 600 VAC 3 Pole J Frame Molded Case Circuit Breaker

JDL36225SA

JDL36225SA is a Square D 225 Amp 3 Pole J Frame Molded Case Circuit Breaker designed for reliable power distribution protection.This circuit breaker features a thermal magnetic trip unit with current limiting and adjustable type characteristics. It is unit mount with a maximum voltage rating of 600 VAC or 250 VDC. The breaker has a D interrupt rating and is UL 489 listed, ensuring compliance with safety standards. Dimensions are approximately 5 in L x 4.12 in W x 7.52 in H.

Key Specifications
• Amperage: 225 Amp
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 3
• Frame/Series: J Frame
• Mounting Type: Unit Mount
• Interrupt Rating: D Interrupt, 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Trip Unit: Thermal Magnetic, Current Limiting, Adjustable
• Certifications: UL 489 Listed
• Dimensions: 5 in L x 4.12 in W x 7.52 in H
• Actuator Type: Toggle
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JDL36225SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDL
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901685883
• GTIN : 00785901685883
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.27
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
