JDA262252 - Square D 225A 600V 2-Pole I-Line Style Plug-In Circuit Breaker, PowerPact J Frame, Thermal Magnetic

JDA262252

JDA262252 is a Square D 2-pole circuit breaker rated for 225 amps and 600 volts, designed for I-Line style plug-in mounting. This PowerPact J Frame breaker features a thermal magnetic trip unit for reliable overcurrent protection. It offers interrupt ratings of 25kA at 240VAC, 18kA at 480VAC, and 14kA at 600VAC, suitable for commercial and industrial applications. The breaker supports AWG 3/0 to 350 kcmil aluminum or copper wiring and is UL, CSA, IEC, CCC, and CE certified.

• Amperage Rating: 225 A
• Voltage Rating: 600 V AC
• Number of Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Frame Size: PowerPact J Frame
• Trip Unit: Thermal Magnetic
• Connection: Line rated I-Line with lugs for load
• Wire Size: AWG 3/0 to 350 kcmil aluminum/copper
• Certifications: UL, CSA, IEC, CCC, CE
• Dimensions: 11.48" H x 4.48" W x 5.87" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDA262252
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDA
• Voltage : 600
• Amperage : 225
• Phase : 1
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901912194
• GTIN : 00785901912194
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
