Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HND63B100L
HND63B100L is a Siemens 3-pole molded case circuit breaker rated for 1000 amps and 600 volts, designed for high interrupt capacity applications.
This breaker features a thermal magnetic trip unit and is part of the Siemens ND frame series. It offers a high interrupt rating of 65kA at 480V and 50kA at 600V, suitable for demanding industrial and commercial power distribution. The breaker includes line and load side lugs supporting wire ranges from 250 to 500 kcmil copper or aluminum conductors.
- Amperage: 1000A
- Voltage Rating: 600V AC
- Poles: 3
- Frame: ND Frame
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 65kA at 480V, 50kA at 600V
- Mounting Type: Lug connection (line and load side)
- Wire Range: 250-500 kcmil CU/AL
- Standards: UL 489, IEC 60947-2
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: HND63B100L
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HND
- Voltage : 600
- Amperage : 1000
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ND Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 783643008823
- GTIN : 00783643008823
- Country of Origin : Mexico
- Weight : 61.489
