HLL26030 - Square D 30A 600V 2-Pole Powerpact H Molded Case Circuit Breaker

HLL26030

HLL26030 is a Square D Powerpact H molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This 2-pole breaker features a 30 ampere rating and supports up to 600 volts AC. It is a thermal magnetic, current limiting type with a frame type H and a feed-thru design suitable for reverse fed applications. The breaker has a high interrupt rating of 125 kA at 240 VAC and 100 kA at 480 VAC, ensuring robust fault current interruption. It includes line and load side lug terminals and a non-interchangeable trip unit with long-time and instantaneous trip functions. UL listed for safety and performance.

Key Specifications
• Amperage: 30 A
• Voltage: 600 VAC max
• Poles: 2
• Frame Type: H
• Interrupt Rating: 125 kA at 240 VAC, 100 kA at 480 VAC
• Trip Unit: Thermal Magnetic, non-interchangeable
• Connection Type: Feed-thru with line and load side lugs
• Mounting Type: Bolt-on
• Certifications: UL Listed
• Suitable for reverse fed applications
• Dimensions: Approx. 4.36 in L x 2.74 in W x 6.4 in H
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HLL26030
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLL
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901659181
• GTIN : 00785901659181
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
