Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJL36125UA
HJL36125UA is a PowerPacT H-Frame molded case circuit breaker manufactured by Schneider Electric, rated for 125 amperes at 600 volts with a 3-pole configuration and 65kA interrupting capacity at 480 volts. This unit mount circuit breaker provides thermal magnetic protection suitable for feed-thru applications and reverse fed installations. The breaker features long-time and instantaneous trip functions with line and load side lug terminals for flexible electrical connections. Key Specifications
- Part Number: HJL36125UA
- Manufacturer: Schneider Electric
- Amperage: 125A
- Voltage: 600VAC
- Poles: 3
- Frame Type: H-Frame
- Interrupting Capacity: 65kA at 480V
- Trip Unit: Thermal Magnetic
- Mounting: Unit Mount
- Connection Type: Lugs
- Certifications: UL 489 Listed, CSA, NEMA, VDE, BS, IEC
- Continuous Current Rating: 80%
Specifications
- Part Number: HJL36125UA
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HJL
- Voltage : 600
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 5
